Chapter 9 LCD Display & Settings
49
For setup procedures, please refer to the following:
1
In the
Main Menu
, select the item you want to configure, press the
ENTER
button
for 0.1 second and the UPS will enter into the setup mode.
2
Press the button
for 0.1 second or press the button
for 0.1 second to
navigate the setting items.
3
Press the button
for 0.1 second to choose the parameter that you want to
FKDQJHDQGWKHSDUDPHWHUZLOOÀDVK
4
Press the button
for 0.1 second or press the button
for 0.1 second to
increase or decrease the parameter value. If either of the buttons is pressed
for over 2 seconds, the LCD will automatically switch between the selectable
values every 0.2 second until either of the buttons is released or the number
reaches its highest or lowest value.
5
Press the button
WRFRQ¿UP\RXUSDUDPHWHUVHWXSRUSUHVVWKHEXWWRQ
ESC
to go back to the previous status.
6
After that, press the button
for 0.1 second or press the button
for 0.1
second to move to the previous or the next setting item.
7
In setup mode, press the
ESC
button and the LCD will exit from the setup
mode.
8
In setup mode, if you don’t press any button for more than 5 minutes, the LCD
will exit from the setup mode and go back to the original display automatically.
Please refer to the
Menu Tree
below for all setting options.
