Chapter 9 Ethernet Specification and Operation
9-39
3. Download
Click the Downloader button on the tool bar to open the Project Downloader window.
Select the Scanner communication port in EIP Builder; every communication port can download a data
mapping table.
9.4.5 Diagnosis
EIP Builder can provide diagnostic information on the connection and data mapping status. For the connection status,
refer to the Adapter connection status and indicator in the Network View tab; and for data mapping status and error
codes, refer to Network_0 in the data mapping tab.
