Delta AS300 Series - Module; Troubleshooting for the Module AS00 SCM as a Communication Module12-23

Chapter 12 Troubleshooting
12-23
12_
IO-Link
Event
Codes
Type
Event Solution
Source
Warning Error
Notifica-
tion
IO-Link
Master
IO-Link
Device
0xFF24 V Data storage not sufficient
Check device
specifications
V
0xFF25 V
Data storage parameter
access denied
Check device
specifications
V
12.3.6 Troubleshooting for the Module AS00SCM as a Communication
Module
12.3.6.1 ERROR LED Indicators Are ON
The following error codes identify possible errors when the AS00SCM module is installed on the right side of the CPU
module and acts as a communication module.
Error
Code
Description Solution
16#1605 Hardware failure
1. Check that the module is securely installed.
2. Install a new AS00SCM or contact the factory.
16#1606 The function card setting is incorrect.
1. Check if the function card is securely installed.
2. Install a new function card or contact the factory.
3. Check if the setting in HWCONFIG is consistent with
the function card setting.
4. Install a new AS00SCM or contact the factory.
12.3.6.2 ERROR LED Indicators Blinking Every 0.5 Seconds
The following error codes identify possible errors when the AS00SCM module is installed on the right side of the CPU
module and acts as a communication module.
Error
Code
Description Solution
16#1802 Incorrect parameters
Check the parameter in HWCONFIG. Download the
parameter again.
16#1803 Communication timeout
1. Check whether the communication cable is
properly connected.
2. Check if the station number and the
communication format are correctly set.
3. Check if the connection with the function card is
working correctly.
16#1804 The UD Link setting is incorrect.
1. Check the settings of the UD Link.
2. Check the warning settings in the PLC.
The following error codes can only be viewed with SCMSoft; when the following errors occur, they are not shown on the
LED indicators and the system does not send the error messages to the CPU module.
Error
Code
Description Solution
16#0107
The settings in HWCONFIG and manual
settings are not consistent with function
card 1.
Check the settings in HWCONFIG and manual
settings for function card 1.
