Delta AS300 Series - Data Type

AS Series Operation Manual
9-66
_9
Object Name Function Class ID
TCP/IP Interface Object
Provides the mechanism to configure a device’s TCP/IP
network interface; examples of configurable items include the
device’s IP Address, Network Mask, and Gateway Address.
245 (H’F5)
Ethernet Link Object
Maintains link-specific counters and status information for an
IEEE 802.3 communications interface.
246 (H’F6)
X Register Bit/Word Register
848（H’350）
Y Register Bit/Word Register
849（H’351）
D Register Bit/Word Register
850（H’352）
M Register Bit Register
851（H’353）
S Register Bit Register
852（H’354）
T Register Bit/Word Register
853（H’355）
C Register Bit/Word Register
854（H’356）
HC Register Bit/Word Register
855（H’357）
SM Register Bit Register
856（H’358）
SR Register Word Register
857（H’359）
9.8.2 Data Type
This section provides an overview of the data types supported by objects.
Data Type Description
BOOL False(H’00) or True(H’01)
SIGNED
INTEGER
SINT(1 byte), INT(2 bytes), DINT(4 bytes), LINT(8 bytes)
Number 1st 2nd 3rd 4th 5th 6th 7th 8th
SINT 0LSB
INT 0LSB 1LSB
DINT 0LSB 1LSB 2LSB 3LSB
LINT 0LSB 1LSB 2LSB 3LSB 4LSB 5LSB 6LSB 7LSB
Example: DINT value = H’12345678
Number 1st 2nd 3rd 4th
DINT 78 56 34 12
