Chapter 6 Control Mode of Operation ASDA-A2R Series
Revision December, 2014
6-27
P2-44 and P2-46. It is suggested to reduce the bandwidth if the resonance has not been
improved. Then use the function of auto resonance suppression.
When manually increase the value of P2-44 and P2-46, please check if the value of both is
bigger than 0. If yes, it means the frequency point of P2-43 and P2-45 is the one searched
by auto resonance suppression. If the value of both is 0, it means the default, 1000 of
P2-43 and P2-45 is not the one searched by auto resonance suppression. Deepen the
resonance suppression attenuation rate might worsen the situation.
P2-47 Function Table
P2-47
Current Value
P2-47
Desire Value
Function
0 1 Clear the value of P2-43~P2-46 and enable the
function of auto resonance suppression.
0 2 Clear the value of P2-43~P2-46 and enable the
function of auto resonance suppression.
1 0 Save the current value of P2-43~P2-46 and
disable the function of auto resonance
suppression.
1 1 Clear the value of P2-43~P2-46 and enable the
function of auto resonance suppression.
1 2 Not clear the value of P2-43~P2-46 and continue
to enable the function of auto resonance
suppression.
2 0 Save the current value of P2-43~P2-46 and
disable the function of auto resonance
suppression.
2 1 Clear the value of P2-43~P2-46 and enable the
function of auto resonance suppression.
2 2 Not clear the value of P2-43~P2-46 and continue
to enable the function of auto resonance
suppression.
