Chapter 1 Inspection and Model Explanation ASDA-A2R Series
Revision December, 2014
1-7
ECML Series Servo Motor_Magnetic Way
ECM L - S M 16 1000 S
Total length of magnetic way
0340: 340 mm
0520: 520 mm
0700: 700 mm
0880: 880 mm
1060: 1060 mm
1240: 1240 mm
Magnetic way dimensions
16: Ø16 mm
20: Ø20 mm
25: Ø25 mm
32: Ø32 mm
Component type
Null: coil assembly
M: magnetic way
Name of the Series
Linear motor type
S = Shaft type coreless
Servo Type
L: Linear servo drive
Product Name
ECM: Electronic Commutation Motor
