Chapter 1 Inspection and Model Explanation ASDA-A2R Series
1-12 Revision December, 2014
Bottom view of the servo drive
Grounding Terminal
Reserved
connector
Connect to motor power
connector (U,V,W) and
cannot connect to the
main circuit power.
Wrong connection may
damage the servo drive.
Servo Motor Output
Connect to power and
motor grounding
