Chapter 2 InstallationASDA-A2R Series
Revision December, 2014
2-17
Dimensions of Regenerative Resistor
Delta part number: BR400W040 (400 W 40Ω)
L1 L2 H D W MAX. WEIGHT (g)
265 250 30 5.3 60 930
Delta part number: BR1K0W020 (1 kW 20Ω)
L1 L2 H D W MAX. WEIGHT (g)
400 385 50 5.3 100 2800
