Delta ASD-A2R-1B43 Series User Manual

Chapter 3 Wiring ASDA-A2R Series
3-26 Revision December. 2014
DI Signal
Name
Operation
Mode
Pin
No
Function
Wiring
Method
(Refer to
3.4.3)
GNUM0
PT, PR,
PT-S, PR-S
-
Electronic gear ratio (numerator) selection 0 (Please refer to
P2-60~P2-62 for gear ratio selection (numerator).)
C9/C10
C11/C12
GNUM1
PT, PR,
PT-S, PR-S
-
Electronic gear ratio (numerator) selection 1 (Please refer to
P2-60~P2-62 for gear ratio selection (numerator).)
INHP PT, PT-S -
In position mode, when this DI is ON, the external pulse
input command is not working.
