Chapter 6 Control Modes of Op
eration
ASD
A-B
2
6-10
Revision May, 2018
6.2.4 Low-pass
Filter
Related parameters:
P1-08
PFLT
Smooth Constant of Position Command
(Low-pass Filter)
Address: 0110H
0111H
Operation
Interface:
Panel/Software
Communic
a
tion
Related Section:
Section 6.2.4
Default:
0
Control
Mode:
PT
Unit: 10
ms
Range:
0 ~ 1000
Data Size:
16-bit
Disp
l
ay
Format:
Decimal
Example:
11 = 110 msec
Settings: 0: Disabled
PF
L
T
T
ar
g
et
p
o
s
iti
on
Posit
ion
Tim
e (ms
)
120
122
