Chapter 2 Installation
ASD
A-B
2
2-18
Revision May, 2018
NOTE
Delta Part Number: BR1K0W020 (1 kW 20
Ω
)
L1
L2
H
D
W
MAX. WEIGHT(g)
400 385
50
5.3
100
2800
Regarding the selection
of regenerative resistor
, please refer to the
table of regenerative resistor spec
ifications
described
in Appendix A.
