Chapter 8 Option Cards CFP2000
8-11
8-5 EMC-BPS01 -- +24V power card
External Power
Supply
Terminals Descriptions
24V
GND
Input power: 24V ± 5%
Maximum input current: 0.5 A
Note:
Do not connect drive control terminal GND directly to the EMC-BPS01
input terminal GND.
Function: When the drive is only powered by EMC-BPS01, the
communications can be assured and support all communication cards
and following functions:
Parameters read and write.
Keypad can be displayed.
Keypad button can be operated (except RUN).
Analog input is effective.
Multi-function (FWD, REV, MI1–MI8) needs external power supply to
operate.
The following functions are NOT supported.
Relay out (including extension card), PG card and PLC function.
