Chapter 7 Optional Accessories CFP2000
7-8
7-2 Magnetic Contactor / Air Circuit Breaker and Non-fuse Circuit Breaker
Magnetic Contactor (MC) and Air Circuit Breaker (ACB)
It is recommended the surrounding temperature for MC should be ≥ 60°C and that for ACB should be
≥ 50°C. In the meanwhile, consider temperature derating for components with ON/OFF switch in
accordance with the ambient temperature of the on-site distribution panel.
Frame Model
Light duty output
current [A]
Light duty input
current [A]
MC/ACB selection
[A]
A
VFD007FP4EA-41/-52/-52S 3 3 7
VFD015FP4EA-41/-52/-52S 4.2 4.2 7
VFD022FP4EA-41/-52/-52S 5.5 5.5 9
VFD037FP4EA-41/-52/-52S 8.5 8.5 18
VFD040FP4EA-41/-52/-52S 10.5 10.5 18
VFD055FP4EA-41/-52/-52S 13 13 22
VFD075FP4EA-41/-52/-52S 18 18 32
B
VFD110FP4EA-41/-52/-52S 24 24 40
VFD150FP4EA-41/-52/-52S 32 32 50
VFD185FP4EA-41/-52/-52S 38 38 65
C
VFD220FP4EA-41/-52/-52S 45 45 75
VFD300FP4EA-41/-52/-52S 60 60 105
VFD370FP4EA-41/-52/-52S 73 73 130
D0
VFD450FP4EA-41/-52/-52S 91 91 150
VFD550FP4EA-41/-52/-52S 110 110 185
D
VFD750FP4EA-41/-52/-52S 150 150 265
VFD900FP4EA-41/-52/-52S 180 180 330
Table 7-4
