Delta CFP2000 Series - Extension Card Parameter

Chapter 11 Summary of Parameter SettingsCFP2000
11-40
14 Extension Card Parameter
Pr. Parameter Name Setting Range Default

14-00
Extension card Input terminal
selection (AI10)
0: Disable
1: Frequency command
0

14-01
Extension card Input terminal
selection (AI11)
4: PID target value
5: PID feedback signal
0
6: Thermistor (PTC) input value
11: PT100 thermistor input value
13: PID compensation amount

14-08 Analog input filter time (AI10) 0.00–20.00 sec. 0.01

14-09 Analog input filter time (AI11) 0.00–20.00 sec. 0.01
14-10
Analog input 4–20 mA signal loss
selection (AI10)
0: Disable
1: Continue operation at the last frequency
2: Decelerate to 0 Hz
3: Stop immediately and display ACE
0
14-11
Analog input 4–20 mA signal loss
selection (AI11)
0

14-12
Extension card output terminal
selection (AO10)
0: Output frequency (Hz)
1: Frequency command (Hz)
0

14-13
Extension card output terminal
selection (AO11)
2: Motor speed (Hz)
3: Output current (rms)
0
4: Output voltage
5: DC bus voltage
6: Power factor
7: Power
9: AVI1 proportional
10: ACI proportional
11: AVI2 proportional
20: CANopen analog output
21: RS-485 analog output
22: Communication card analog output
23: Constant voltage output

14-14
Analog output 1 gain output
(AO10)
0.0–500.0% 100.0

14-15
Analog output 1 gain output
(AO11)
0.0–500.0% 100.0

14-16
Analog output 1 in REV direction
(AO10)
0: Absolute value of output voltage
1: Reverse output 0 V; Forward output 0–10 V
2: Reverse output 5–0 V; Forward output 5–10 V
0

14-17
Analog output 1 in REV direction
(AO11)
0
