Chapter 7 Optional Accessories CFP2000
7-10
7-3 Fuse Specification Chart
 Fuses specification lower than the table below are allowed.
 For installation in the United States, branch circuit protection must be provided in accordance with
the National Electrical Code (NEC) and any applicable local codes. Use UL classified fuses to fulfill
this requirement.”
 For installation in Canada, branch circuit protection must be provided in accordance with Canadian
Electrical Code and any applicable provincial codes. Use UL classified fuses to fulfill this
requirement.”
Model
Input Current I [A] Line Fuse
Light Duty Normal Duty I [A] Bussmann P/N
VFD007FP4EA-41/-52/-52S
3.0 1.7 6 JJS-6
VFD015FP4EA-41/-52/-52S
4.2 3 6 JJS-6
VFD022FP4EA-41/-52/-52S
5.5 4 10 JJS-10
VFD037FP4EA-41/-52/-52S
8.5 6 15 JJS-15
VFD040FP4EA-41/-52/-52S
10.5 9 15 JJS-15
VFD055FP4EA-41/-52/-52S
13 10.5 20 JJS-20
VFD075FP4EA-41/-52/-52S
18 12 25 JJS-25
VFD110FP4EA-41/-52/-52S
24 18 35 JJS-35
VFD150FP4EA-41/-52/-52S
32 24 50 JJS-50
VFD185FP4EA-41/-52/-52S
38 32 60 JJS-60
VFD220FP4EA-41/-52/-52S
45 38 60 JJS-60
VFD300FP4EA-41/-52/-52S
60 45 90 JJS-90
VFD370FP4EA-41/-52/-52S
73 60 100 JJS-100
VFD450FP4EA-41/-52/-52S
91 73 125 JJS-125
VFD550FP4EA-41/-52/-52S
110 91 150 JJS-150
VFD750FP4EA-41/-52/-52S
150 110 200 JJS-200
VFD900FP4EA-41/-52/-52S
180 150 250 JJS-250
Table 7-6
