9-2 Environment for Operation, Storage and Transportation
Do NOT expose the AC motor drive in the bad environment, such as dust, direct sunlight, corrosive/inflammable gasses,
humidity, liquid and vibration environment. The salt in the air must be less than 0.01mg/cm
2
every year.
Environment
Installation
location
IEC60364-1/IEC60664-1 Pollution degree 2, Indoor use only
Surrounding
Temperature
(°C)
Operation
- 15– + 50 without derating,
+51–60 with derating
Storage
-25– +70
Transportation
-25– +70
Non-condensation, non-frozen
Rated Humidity
Operation
Max. 95%
Storage/
Transportation
Max. 95%
No condense water
Air Pressure
(kPa)
Operation/
Storage
86–106
Transportation
70–106
Pollution Level
IEC 60721-3-3
Operation
Class 3C3, Class 3S2
Storage
Class 1C2, Class 1S2
Transportation
Class 2C2, Class 2S2
Altitude
Operation
If the AC motor drive is installed at an altitude 0–1000 m, follow normal
operation restriction. For every 100 m increase in altitude, the AC motor
drive needs to either lower rated current by 1% or by 0.5
o
C of
temperature for operation.
If the drive is installed at an altitude above 2000 m, please refer to the
voltage derating graph in the user manual for more instructions.
Note: Voltage derating is not needed for a Center Ground System, and
maximum installation altitude is 4000m.
Vibration
Operating
IEC 60068-2-6
Frame A: 2 Hz ≦ f ≦ 13.2 Hz / Amplitude 1 mm; 13.2 Hz < f ≦ 55 Hz / Gravity 0.7 G to 2.0 G;
55 Hz < f ≦ 512 Hz / Gravity 2.0 G
Frame B: 2 Hz ≦ f ≦ 13.2 Hz / Amplitude 1 mm; 13.2 Hz < f ≦ 55 Hz / Gravity 0.7 G to 1.5 G;
55 Hz < f ≦ 512 Hz / Gravity 1.5 G
Frame C / D0 / D:
2 Hz ≦ f ≦ 13.2 Hz / Amplitude 1 mm; 13.2 Hz < f ≦ 55 Hz / Gravity 0.7 G to 1.0 G;
55 Hz < f ≦ 512 Hz / Gravity 1.0 G
Shock
Operating
IEC 60068-2-27
Frame A; B; C; D0: Max 30 G; 11 ms
Frame D: Max 15 G; 11 ms
In protective
shipping
package
Vibration
IEC 60068-2-64
10Hz
≦
f
≦
100Hz / ASD: 1.0m2/s3
100Hz
≦
f
≦
200Hz / Slope: -3dB/octave
Shock
Cardboard box type: Free fall drop in accordance with ISTA 1A
Wooden box type: In accordance with ISTA 1E (4 side incline) and ISTA 2B (Bottom side drop)
Operation
Position
Maximum permanent angle in relation to the normal vertical
mounting position
10 10
