Chapter 12 Description of Parameter SettingsCFP2000
12.1-06-2

Selection for Stall Prevention
Default: 0
Settings 0: Traditional over-voltage and traditional over-current stall prevention
1: Smart over-voltage and traditional over-current stall prevention
2: Traditional over-voltage and smart over-current stall prevention
3: Smart over-voltage and smart over-current stall prevention
 A comparison between traditional stall prevention and smart stall prevention:
Type
Over-voltage Over-current
Description Action Parameter Description Action Parameter
Traditional
Frequency
maintains during
deceleration
Deceleration
stops
Pr.06-01
Frequency
maintains during
acceleration
Acceleration
stops
Pr.06-03
Frequency
decreases at
constant speed
Frequency
gradually
decreases
Pr.06-04
Smart
Frequency
increases during
acceleration /
deceleration /
constant speed
Frequency
gradually
increases
Pr.06-01
Frequency
decreases
during
acceleration /
deceleration
Frequency
gradually
decreases
Pr.06-03
Frequency
decreases at
constant speed
Frequency
gradually
decreases
Pr.06-04
 Pr.06-02 (Selection for stall prevention) can be used with Pr.01-49 (Regenerative energy
restriction control method), but Pr.06-02 cannot work with Pr.01-44 (Auto-acceleration and
auto-deceleration setting).
 When Pr.06-02 or Pr.01-49 is enabled (setting value > 0), Pr.01-44 (Auto-acceleration and
auto-deceleration setting) automatically disables (setting value = 0) and cannot be set; when
Pr.01-44 is enabled (setting value > 0), Pr.06-02 and Pr.01-49 automatically disable and cannot
be set.
 If you use smart over-voltage or smart over-current stall prevention for industries that require fast
response, you can decrease the deceleration time when needed.
 Related parameters:
Pr.06-01 Over-voltage stall prevention, Pr.06-03 Over-current stall prevention during acceleration,
Pr.06-04 Over-current stall prevention during operation, Pr.06-05 Acceleration / deceleration time
selection for stall prevention at constant speed, Pr.01-12–01-19 Acceleration / Deceleration time
1–4, and Pr.02-13–02-15 Multi-function output (Relay 1–3).
