Chapter 3 UnpackingCFP2000
3-2
The AC motor drive should be kept in the shipping carton or crate before installation. In order to retain the
warranty coverage, the AC motor drive should be stored properly when it is not to be used for an
extended period of time.
3-1 Unpacking
Follow these steps to unpack the AC motor drive:
Frame D0
VFD450FP4EA-41, VFD450FP4EA-52, VFD450FP4EA-52S,
VFD550FP4EA-41, VFD550FP4EA-52, VFD550FP4EA-52S
1. Remove the 4 clips by slotted screwdriver.
2. Remove the cover of wood box and then take out the EPE tray and user manual.
To Next Page
