Chapter 16 PLC Function Applications│CFP2000
16-40
16-5-4 PLC Communication address
Device Range Type Address (Hex)
X 00–37 (Octal) bit 0400–041F
Y 00–37 (Octal) bit 0500–051F
T 00–159 bit/word 0600–069F
M 000–799 bit 0800–0B1F
M 1000–1079 bit 0BE8–0C37
C 0–79 bit/word 0E00–0E47
D 00–399 word 1000–118F
D 1000–1198 word 13E8–144B
D 2000–2799 word 17D0–1AEF
Command code that can be used
Function Code Description of Function Function target
01 Coil status read Y, M, T, C
02 Input status read X, Y, M, T, C
03 Read single unit of data T, C, D
05 Compulsory single coil status change Y, M, T, C
06 Write single unit of data T, C, D
0F Compulsory multiple coil status change Y, M, T, C
10 Write multiple units of data T, C, D
NOTE
When PLC functions have been activated, the CFP2000 can match PLC and driver parameters; this method
employs different addresses and driver (default station number is 1, PLC sets station number as 2).
