Chapter 5 Main Circuit TerminalsCFP2000
5-6
Frame A-1/A-3
V/T2 W/T3 B2 B1
-
U/T1
 If you install at Ta 40°C environment, please select copper wire with voltage rating 600 V and
temperature resistant at 75°C or 90°C.
 If you install at Ta 40°C above environment, please select copper wire with voltage rating 600 V and
temperature resistant at 90°C or above.
 For UL installation compliant, please use copper wires for installation, the wire gauge is based on
temperature resistant at 75°C which is requested and recommended from UL. Do not reduce the
wire gauge when using higher temperature wire.
Model Nam
Main Circuit Terminals:
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3, B1, B2
Terminals:
, DC-, DC+
Max. Wire
Gauge
Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
Max. Wire
Gauge
Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
VFD007FP4EA-41/52
12 AWG
[4 mm
2
]
12 AWG [4 mm
2
]
M3.5
10 kg-cm
[8.7 lb-in.]
[0.98 Nm]
10 AWG
[6 mm
2
]
12 AWG [4 mm
2
]
M4.0
18 kg-cm
[15.6 lb-in.]
[1.77 Nm]
VFD015FP4EA-41/52
12 AWG [4 mm
2
]
12 AWG [4 mm
2
]
VFD022FP4EA-41/52
12 AWG [4 mm
2
]
12 AWG [4 mm
2
]
VFD037FP4EA-41/52
12 AWG [4 mm
2
]
12 AWG [4 mm
2
]
VFD040FP4EA-41/52
10 AWG
[6 mm
2
]
12 AWG [4 mm
2
]
M4.0
18 kg-cm
[15.6 lb-in.]
[1.77 Nm]
12 AWG [4 mm
2
]
VFD055FP4EA-41/52
10 AWG [6 mm
2
] 10 AWG [6 mm
2
]
VFD075FP4EA-41/52
10 AWG [6 mm
2
] 10 AWG [6 mm
2
]
