Chapter 7 Optional AccessoriesCFP2000
7-3
Models and Specifications Comparison Table of Wire Wound Resistors:
1-2 Aluminum housed resistors: for below 1000W, refer to the following appearance of aluminum-housed
resistor (Figure 7-2) and its model and specification comparison table (Table 7-3) for details.
A
W
L1
L 2
L
H
L3
12.0
16AWG, 1.318MM2
Table 7-2
Figure 7-2
Table 7-3
Unit: mm
