Delta CP2000 Series User Manual

Chapter 7 Optional AccessoriesCP2000
7-34
Model kW HP
Rated Amps of
DC Reactor
[Arms]
Max. continuous
Amps [Arms]
DC impedance
[mH]
DC Reactor
Delta part #
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
220 22 30 75 90 120 108 0.391 0.325 DR075DP391 DR090DP325
300 30 40 90 105 144 126 0.325 0.244 DR090DP325 Contact Delta
*Note 1: Use with DR005D0585, but the inductance value will be 3% short.
380V–460V, 50 / 60 Hz
Model kW HP
Rated Amps of
DC Reactor
[Arms]
Max. continuous
Amps [Arms]
DC impedance
[mH]
DC Reactor
Delta part #
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
007 0.75 1 2.8 3 4.48 3.6 18.709 18.709 DR003D1870 DR003D1870
015 1.5 2 3 4.2 4.8 5.04 18.709 14.031 DR003D1870 DR004D1403
022 2.2 3 4 5.5 6.4 6.6 14.031 9.355 DR004D1403 DR006D0935
037 3.7 5 6 8.5 9.6 10.2 9.355 6.236 DR006D0935 DR009D0623
040 4 5 9 10.5 14.4 12.6 6.236 5.345 DR009D0623 DR010D0534
055 5.5 7.5 10.5 13 16.8 15.6 5.345 4.677 DR010D0534 DR012D0467
075 7.5 10 12 18 19.2 21.6 4.677 3.119 DR012D0467 DR018D0311
110 11 15 18 24 28.8 28.8 3.119 2.338 DR018D0311 DR024D0233
150 15 20 24 32 38.4 38.4 2.338 1.754 DR024D0233 DR032D0175
185 18.5 25 32 38 51.2 45.6 1.754 1.477 DR032D0175 DR038D0147
220 22 30 38 45 60.8 54 1.477 1.247 DR038D0147 DR045D0124
300 30 40 45 60 72 72 1.247 0.935 DR045D0124 DR060DP935
370 37 50 60 73 96 87.6 0.935 0.768 DR060DP935 Contact Delta
*Note 1: Use with DR003D1870, but the inductance value will be 3% short.
575 V, 50 / 60 Hz, 3-phase
Model kW HP
Rated Amps of
DC Reactor
[Arms]
Max. continuous Amps
[Arms]
DC impedance
[mH]
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
015 1.5 2 2.5 3 4.2
29.284 24.404
022 2.2 3 3.6 4.3 5.9
20.336 17.027
037 3.7 5 5.5 6.7 9.1
13.310 10.927
055 5.5 7.5 8.2 9.9 13.7
8.929 7.394
075 7.5 10 10 12.1 16.5
7.322 6.050
110 11 15 15.5 18.7 25.7
4.722 3.916
150 15 20 20 24.2 33.3
3.661 3.026
Table 7-40
Table 7-41
Table 7-42

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
