Delta CP2000 Series User Manual

Chapter 7 Optional AccessoriesCP2000
7-61
575V/690V Series
Frame Model
Input
Current
[A]
Applicable EMC Filter
Zero Phase*
Reactor
CE Cable Length Radiation Emission
default carrier frequency
C1 C2 EN61800-3
A
VFD022CP53A-21 5.4 EMF008A63A
RF008X00A
50m 100m C2
VFD037CP53A-21 10.4 EMF014A63A
B
VFD055CP53A-21 14.9
EMF027A63A
VFD075CP53A-21 16.9
VFD110CP53A-21 21.3
VFD150CP53A-21 26.3
C
VFD185CP63A-21 29
B84143A0050R021 RF002X00A
VFD220CP63A-21 36
VFD300CP63A-21 43
VFD370CP63A-21 54
D
VFD450CP63A-00
VFD450CP63A-21
54
VFD550CP63A-00
VFD550CP63A-21
67
E
VFD750CP63A-00
VFD750CP63A-21
84
B84143A0120R021
RF300X00A
VFD900CP63A-00
VFD900CP63A-21
102
VFD1100CP63A-00
VFD1100CP63A-21
122
B84143B0150S021
VFD1320CP63A-00
VFD1320CP63A-21
147
F
VFD1600CP63A-00
VFD1600CP63A-21
178
B84143B0250S021
VFD2000CP63A-00
VFD2000CP63A-21
217
G
VFD2500CP63A-00
VFD2500CP63A-21
292
B84143B0400S021
RF300X00A
50m 100m C2
VFD3150CP63A-00
VFD3150CP63A-21
353
H
VFD4000CP63A-00
VFD4000CP63A-21
454
B84143B0600S021
VFD4500CP63A-00
VFD4500CP63A-21
469
H
VFD5600CP63A-00
VFD5600CP63A-21
595
B84143B0600S021
VFD6300CP63A-00
VFD6300CP63A-21
681
B84143B1000S021
* For Frame A–C: On both input and output side, a zero phase reactor is required to be wired to the motor drive.
There should be in total 2 zero phase reactors.
For Frame D–H: Only one zero phase reactor is required to be wired on the output side of the motor drive.
Table 7-74
