Chapter 11 Summary of Parameter SettingsCP2000
11-8
01 Basic Parameters
Pr. Parameter Name Settings Range Default
01-00 Maximum operation frequency
50.00–599.00 Hz
Setting range for/including 45 kW (60 HP) and
above: 0.00–400 Hz
60.00 /
50.00
01-01 Output frequency of motor 1 0.00–599.00 Hz
60.00 /
50.00
01-02 Output voltage of motor 1
230V: 0.0–255.0 V
460V: 0.0–510.0 V
575V: 0.0–637.0 V
690V: 0.0–765.0 V
200.0
400.0
575.0
660.0
01-03 Mid-point frequency 1 of motor 1 0.00–599.00 Hz
3.00 /
0.00
01-04 Mid-point voltage 1 of motor 1
230V: 0.0–240.0 V
460V: 0.0–480.0 V
575V: 0.0–637.0 V
690V: 0.0–720.0 V
*690V, with 185 kW and above: 10.0
11.0
22.0
0.0
0.0
01-05 Mid-point frequency 2 of motor 1 0.00–599.00 Hz
1.50
01-06 Mid-point voltage 2 of motor 1
230V: 0.0–240.0 V
460V: 0.0–480.0 V
575V: 0.0–637.0 V
690V: 0.0–720.0 V
*690V, with 185 kW and above: 2.0
5.0
10.0
0.0
0.0
01-07 Min. output frequency of motor 1 0.00–599.00 Hz
1.50
01-08 Min. output voltage of motor 1
230V: 0.0–240.0 V
460V: 0.0–480.0 V
575V: 0.0–637.0 V
690V: 0.0–720.0 V
1.0
2.0
0.0
0.0
01-09 Start-up frequency 0.00–599.00 Hz
0.50
01-10 Output frequency upper limit 0.00–599.00 Hz
599.00
01-11 Output frequency lower limit 0.00–599.00 Hz
0.00
01-12 Acceleration time 1
Pr.01-45=0: 0.00–600.00 sec.
Pr.01-45=1: 0.0–6000.0 sec.
Motor drive with 230V/460V/690V, 22 kW and above:
60.00 / 60.0
Motor drive with 690V, 160 kW and above: 80.00 / 80.0
10.00
01-13 Deceleration time 1
Pr.01-45=0: 0.00–600.00 sec.
Pr.01-45=1: 0.0–6000.0 sec.
Motor drive with 230V/460V/690V, 22 kW and above:
60.00 / 60.0
Motor drive with 690V, 160 kW and above: 80.00 / 80.0
10.00
01-14 Acceleration time 2
Pr.01-45=0: 0.00–600.00 sec.
Pr.01-45=1: 0.0–6000.0 sec.
Motor drive with 230V/460V/690V, 22 kW and above:
60.00 / 60.0
Motor drive with 690V, 160 kW and above: 80.00 / 80.0
10.00
