Delta CP2000 Series User Manual

Chapter 11 Summary of Parameter SettingsCP2000
11-9
Pr. Parameter Name Settings Range Default

01-15 Deceleration time 2
Pr.01-45=0: 0.00–600.00 sec.
Pr.01-45=1: 0.0–6000.0 sec.
Motor drive with 230V/460V/690V, 22 kW and above:
60.00 / 60.0
Motor drive with 690V, 160 kW and above: 80.00 / 80.0
10.00

01-16 Acceleration time 3
Pr.01-45=0: 0.00–600.00 sec.
Pr.01-45=1: 0.0–6000.0 sec.
Motor drive with 230V/460V/690V, 22 kW and above:
60.00 / 60.0
Motor drive with 690V, 160 kW and above: 80.00 / 80.0
10.00

01-17 Deceleration time 3
Pr.01-45=0: 0.00–600.00 sec.
Pr.01-45=1: 0.0–6000.0 sec.
Motor drive with 230V/460V/690V, 22 kW and above:
60.00 / 60.0
Motor drive with 690V, 160 kW and above: 80.00 / 80.0
10.00

01-18 Acceleration time 4
Pr.01-45=0: 0.00–600.00 sec.
Pr.01-45=1: 0.0–6000.0 sec.
Motor drive with 230V/460V/690V, 22 kW and above:
60.00 / 60.0
Motor drive with 690V, 160 kW and above: 80.00 / 80.0
10.00

01-19 Deceleration time 4
Pr.01-45=0: 0.00–600.00 sec.
Pr.01-45=1: 0.0–6000.0 sec.
Motor drive with 230V/460V/690V, 22 kW and above:
60.00 / 60.0
Motor drive with 690V, 160 kW and above: 80.00 / 80.0
10.00

01-20 JOG acceleration time
Pr.01-45=0: 0.00–600.00 sec.
Pr.01-45=1: 0.0–6000.0 sec.
Motor drive with 230V/460V/690V, 22 kW and above:
60.00 / 60.0
Motor drive with 690V, 160 kW and above: 80.00 / 80.0
10.00

01-21 JOG deceleration time
Pr.01-45=0: 0.00–600.00 sec.
Pr.01-45=1: 0.0–6000.0 sec.
Motor drive with 230V/460V/690V, 22 kW and above:
60.00 / 60.0
Motor drive with 690V, 160 kW and above: 80.00 / 80.0
10.00

01-22 JOG frequency 0.00–599.00 Hz
6.00

01-23
First / Fourth acceleration /
deceleration frequency
0.00–599.00 Hz
0.00

01-24 S-curve acceleration begin time 1
Pr.01-45=0: 0.00–25.00 sec.
Pr.01-45=1: 0.0–250.0 sec.
0.20

01-25 S-curve acceleration arrival time 2
Pr.01-45=0: 0.00–25.00 sec.
Pr.01-45=1: 0.0–250.0 sec.
0.20

01-26 S-curve deceleration begin time 1
Pr.01-45=0: 0.00–25.00 sec.
Pr.01-45=1: 0.0–250.0 sec.
0.20

01-27 S-curve deceleration arrival time 2
Pr.01-45=0: 0.00–25.00 sec.
Pr.01-45=1: 0.0–250.0 sec.
0.20
01-28
Skip frequency 1 (upper limit)
0.00–599.00 Hz 0.00
01-29
Skip frequency 1 (lower limit)
0.00–599.00 Hz 0.00

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
