Delta DVP-ES2

5 Temperature Measurement Module DVP04TC-E2
 For voltag
e input Mode 7: 1
SCALE
= 80mV/8000=0.01 mV.
Equation:








 Offset
V
VX
Y
)m(01.0
)m (
Y=Digital output, X= voltage input
5.7.1 Conversion Curve
 Mode 0 (H’0000): J-type,
°C (°F)
+11500(21020)
-1000(-1480)
+1150-100
C
C
F)
(-148
F)
(+2102
Measured
temperature
input
Digital output
Mode 0 of CR#2~ CR#5 -100°C ~ 1150°C (-1000~11500)
-148°F ~ 2102°F (-1480~21020)
Offset (CR#34 ~ CR#37) Offset value
 Mode 1 (H’0001): K-type, °C (°F)
+13500(24620)
-1000(-1480)
+1350-100
C
C
F)
(-148
F)
(+2462
Measured
temperature
input
Digital output
Mode 1 of CR#2~ CR#5 -100°C ~ 1350°C (-1000~13500)
-148°F ~ 2462°F (-1480~24620)
Offset (CR#34 ~ CR#37) Offset value
 Mode 2 (H’0002): R-type, °C (°F), Mode 3 (H’0003): S-type, °C (°F)
+17500(31820)
0(320)
+17500
C
C
F)
(32
F)
(+3182
Measured
temperature
input
Digital output
Mode 2, 3 of CR#2~ CR#5 0°C ~ 1750°C (0~17500)
32°F ~ 3182°F (320~31820)
Offset (CR#34 ~ CR#37) Offset value
DVP-ES2 Module Manual
5-12
