4 Temperature Measurement Module DVP04PT-E2
DVP-ES2 Module Manual
-4
DVP04PT-E2
CR# Save Register content
Description
#20 NO R Present temperature measured at CH1
#21 NO R Present temperature measured at CH2
#22 NO R Present temperature measured at CH3
#23 NO R Present temperature measured at CH4
Present temperature measured at CH1 ~ CH4.
Temperature u ni t: set in CR# 7
#24 ~ #27 Reserved
#28 YES R/W Adjusted Offset value of CH1
#29 YES R/W Adjusted Offset value of CH2
#30 YES R/W Adjusted Offset value of CH3
#31 YES R/W Adjusted Offset value of CH4
Set the adjusted Offset value of Ch1 ~ Ch4. Default = K0
Range: K-400~K400
Definition of Offset at Ch1 ~ Ch4 in DVP04PT-E2:
Deviation digital value from the target temperature/voltage.
#32 ~ #39 Reserved
#40 YES R/W
Function: Set value changing
prohibited
Prohibit set value changing in CH1 ~ CH4
#41 NO R/W Function: Save all the set values Save all the set values, Default =H’0000
#42 NO R/W Function: Return to default setting Set all values to default setting, Default = H’0000
#43 NO R Error status
Register for storing all error status. See the table of error status for
more information.
#44 ~ #99 Reserved
#100 YES R/W
Function: Enable/Disable limit
detection
Enable/Disable the upper and lower bound detection function
#101 NO R/W Upper and lower bound status Display the upper and lower bound value, Default =H’0000
#102 YES R/W Set value of CH1 upper bound
#103 YES R/W Set value of CH2 upper bound
#104 YES R/W Set value of CH3 upper bound
#105 YES R/W Set value of CH4 upper bound
Set value of CH1~CH4 upper bound. Default = K32,000
#106 ~ #107 Reserved
#108 YES R/W Set value of CH1 lower bound
#109 YES R/W Set value of CH2 lower bound
#110 YES R/W Set value of CH3 lower bound
#111 YES R/W Set value of CH4 lower bound
Set value of CH1~CH4 lower bound. Default = K-32,000
#112 ~ #119 Reserved
DVP04PT-E2
CR#
CH1 CH2 CH3 CH4
Save Register content
Description
#120 #140 #160 #180 YES R/W SV (Setpoint)
Please set the temperature value according to proper range of
each sensor type. Default = K0
#121 #141 #161 #181 YES R/W Sampling time (s) Range: K1 ~ K30 (s). Default = K2
#122 #142 #162 #182 YES R/W K
P
Proportional control constant. Default = K121
#123 #143 #163 #183 YES R/W K
I
Integral constant. Default = K2,098
#124 #144 #164 #184 YES R/W K
D
Derivative constant. Default = K-29.
#125 #145 #165 #185 YES R/W Upper limit of I value Upper limit of I value. Default = K0
#126 #146 #166 #186 YES R/W Lower limit of I value Lower limit of I value. Default = K0.
#127 #147 #167 #187 NO R I value Current accumulated offset value.
#128 #148 #168 #188 YES R/W Heating/cooling 0: Heater, 1: Cooler. Default = K0
#129 #149 #169 #189 YES R/W Upper limit of output Upper limit of output. Default = K32,000
#130 #150 #170 #190 YES R/W Lower limit of output Lower limit of output. Default = K0
#131 #151 #171 #191 NO R Output percentage (%) Output percentage (Unit: 0.1%)
#132 #152 #172 #192 NO R Output width (ms) Width of control output. Unit: ms.
#133 #153 #173 #193 NO R Output cycle (ms) Cycle of control output. Unit: ms.
#134 #154 #174 #194 NO R Output volume Output volume
#135 #155 #175 #195 NO R/W PID_RUN/STOP 0: STOP, 1: RUN. Default = K0
#136 #156 #176 #196 NO R/W Auto-tuning 0: Disabled, 1: Auto-tuning. Default = K0
Symbols:
YES: When CR#41 is set to H’5678, the set value of CR will be saved. NO: Set value will not be saved
R: Able to read data by FROM instruction, W: Able to write data by using TO instructions
4.6.2 Explanation on CR
CR#0: Model name
[Explanation]
1. DVP04PT-E2 model code = H’0082.
2. You can read the model name in the program to see if the extension module exists.
