DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3-364
Register
Data
Descriptions
D1256 Low byte
‘0’
30 H
ADR 1
Address of VFD-B: ADR (1,0)
D1256 High byte
‘1’
31 H
ADR 0
D1257 Low byte
‘0’
30 H
CMD 1
Control parameter: CMD (1,0)
D1257 High byte
‘3’
33 H
CMD 0
D1258 Low byte
‘2’
32 H
Data Address
D1258 High byte
‘1’
31 H
D1259 Low byte
‘0’
30 H
D1259 High byte
‘0’
30 H
Register
Data
Descriptions
D1260 Low byte
‘0’
30 H
Number of data (count by word)
D1260 High byte
‘0’
30 H
D1261 Low byte
‘0’
30 H
D1261 High byte ‘6’ 36 H
D1262 Low byte
‘D’
44 H
LRC CHK 1
Checksum: LRC CHK (0,1)
D1262 High byte
‘5’
35 H
LRC CHK 0
Registers for received data (responding messages)
Register
Data
Descriptions
D0 low byte
‘0’
30 H
ADR 1
D0 high byte
‘1’
31 H
ADR 0
D1 low byte
‘0’
30 H
CMD 1
D1 high byte
‘3’
33 H
CMD 0
D2 low byte
‘0’
30 H
Number of data (count by byte)
D2 high byte
‘C’
43 H
D3 low byte
‘0’
30 H
Content of
address H2100
0100 H
PLC COM2 automatically
converts ASCII codes to Hex
and stores the converted
value in D1296
D3 high byte
‘1’
31 H
D4 low byte
‘0’
30 H
D4 high byte ‘0’ 30 H
D5 low byte
‘1’
31 H
Content of
address H2101
1766 H
PLC COM2 automatically
converts ASCII codes to Hex
and stores the converted
value in D1297
D5 high byte
‘7’
37 H
D6 low byte
‘6’
36 H
D6 high byte ‘6’ 36 H
D7 low byte
‘0’
30 H
Content of
address H2102
0000 H
PLC COM2 automatically
converts ASCII codes to hex
and stores the converted
value in D1298
D7 high byte
‘0’
30 H
D8 low byte
‘0’
30 H
D8 high byte ‘0’ 30 H
D9 low byte
‘0’
30 H
Content of
address H2103
0000 H
PLC COM2 automatically
converts ASCII codes to hex
and stores the converted
value in D1299
D9 high byte
‘0’
30 H
D10 low byte
‘0’
30 H
D10 high byte ‘0’ 30 H
Register
Data
Descriptions
D11 low byte
‘0’
30 H
Content of
address H2104
0136 H
PLC COM2 automatically
converts ASCII codes to hex
and stores the converted
value in D1300
D11 high byte
‘1’
31 H
D12 low byte
‘3’
33 H
D12 high byte ‘6’ 36 H
