EtherCAT Communication Card: CMM-EC02/ CMM-EC03
CMM-EC02/ CMM-EC03 Operation Manual
49
Appendix A.
A.1 Description of Object Specification
A.1.1 Object Type
Object Type
Description
Variable
A single value such as a UNSIGNED8, a Boolean, a float and an INTEGER16
Array
An object with multiple data fields composed of multiple variables of the same data
type such as UNSIGNED16. The Sub-index 0 data belongs to UNSIGNED8, so it’s not
classified as array data
Record
An object with multiple data fields composed of multiple variables of the same data
type. The Sub-index 0 data belongs to UNSIGNED8, so it’s not classified as record
data.
A.1.2 Data Type
Data Type
Data Size
Range
BOOLEAN
1 bit
0~1
UNSIGNED8
1 byte
0~255
UNSIGNED16
2 bytes
0~65535
UNSIGNED32
4 bytes
0~4294967295
INTEGER8
1 byte
-128~127
INTEGER16
2 bytes
-32768~327671
INTEGER32
4 bytes
-2147483648~2147483647
VISIBLE STRING
-
-
