Rear Compartment Locations
Figure 13. Open Compartment, Rear View
Table 12: Open Compartment, Rear View
No. Description No. Description
1 IGBT HSK cover 2
Ventilation fan module-IGBT (IGBT fan
module)
3 AC filter module (C Board) (Visible) 4 Inverter module (IGBT HSK)
1
2
3
4
