Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-02-16
Settings Functions Descriptions
03-46: The low level of analog input, factory setting is 10%.
If analog input > 03-45, then multi-function output terminal
operates.
If analog input < 03-46, then multi-function output terminal stops
outputting.
69
Output Command of
Preheating
When MI =69 and the terminal contact is ON, the preheat function
will be activated while the motor drive is at STOP. The MO
terminal will indicate the preheating output.
When the MI terminal contact is OFF or when the motor drive is at
RUN, the preheat function and the output command will be
deactivated. See Pr02-72 and Pr02-73 for more information.
Reserved
Reserved
Multi-function Output Setting
Factory Setting: 0000h
Settings 0000h~FFFFh (0:N.O. ; 1:N.C.)
The setting of this parameter is in hexadecimal.
This parameter is set via bit setting. If a bit is 1, the corresponding multi-function output acts in the
opposite way.
Example:
If Pr02-13=1 and Pr02-18=0, Relay 1 is ON when the drive runs and is open when the drive is
stopped.
If Pr02-13=1 and Pr02-18=1, Relay 1 is open when the drive runs and is closed when the drive is
stopped.
Bit setting
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
MO20 MO19 MO18 MO17 MO16 MO15 MO14 MO13 MO12 MO11 MO10 MO2 MO1 Reserved RY2 RY1
Terminal Counting Value Attained (return to 0)
Factory Setting: 0
Settings 0~65500
The counter trigger can be set by the multi-function terminal MI6 (set Pr.02-06 to 23). Upon
completion of counting, the specified multi-function output terminal will be activated
(Pr.02-13~02-14, Pr.02-36, 02-37 is set to 18). Pr.02-19 can’t be set to 0.
When the display shows c5555, the drive has counted 5,555 times. If display shows c5555•, it
means that real counter value is between 55,550 to 55,559.
Preliminary Counting Value Attained (not return to 0)
Factory Setting: 0
Settings 0~65500
When the counter value counts from 1 and reaches this value, the corresponding multi-function
output terminal will be activated, provided one of Pr. 02-13, 02-14, 02-36, 02-37 set to 17
(Preliminary Count Value Setting). This parameter can be used for the end of the counting to
