AFM2 Filter Output Time
Factory Setting: 0.01
Settings 0.00~20.00 Seconds
~
Reserved
MO by AI level
Factory Setting: 0
Settings 0: AVI1
1: ACI
2: AVI2
AI Upper level
Factory Setting: 50.00%
Settings -100.00%~100.00%
AI Lower level
Factory Setting: 100.00%
Settings -100.00%~100.00%
This function requires working with Multi-function Output item “67” Analog signal level achieved.
The MO active when AI input level is higher than Pr03-45 AI Upper level. The MO shutoffs when
the AI input is lower that Pr03-46 AI Lower level.
AI Upper level must be higher than AI Lower level
~
Reserved
Analog Input Curve Selection
Factory Setting: 0
Settings 0: Regular Curve
1: 3 point curve of AVI1
2: 3 point curve of ACI
3: 3 point curve of AVI 1& ACI
4: 3 point curve of AVI2
5: 3 point curve of AVI 1& AVI2
6: 3 point curve of ACI & AVI2
7: 3 point curve of AVI1 & ACI & AVI2
Set Pr03-50 = 0, all analog input signal are calculated by using bias and gain.
Set Pr03-50 =1, AVI1 is calculated by using frequency and voltage/current in corresponding
format (Pr03-51 ~ Pr03-56), other analog input signals are calculated by using bias and gain.
