Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-03-24
Set Pr03-50 =2, ACI is calculated by using frequency and voltage/current in corresponding format
(Pr03-57 ~ Pr03-62), other analog input signals are calculated by using bias and gain.
Set Pr03-50 =3, AVI1 and ACI are calculated by using frequency and voltage/current in
corresponding format (Pr03-51 ~ Pr03-62), other analog input signals are calculated by using
bias and gain.
Set Pr03-50 =4, AVI2 is calculated by using frequency and voltage in corresponding format
(Pr03-63 ~ Pr03-68), other analog input signals are calculated by using bias and gain.
Set Pr03-50=5, AVI and AVI2 are calculated by using frequency and voltage/current in
corresponding format (Pr03-51~ Pr03-5, Pr03-63~Pr03-68), other analog input signal are
calculated by using bias and gain.
Set Pr03-50=6, ACI and AVI2 are calculated by using frequency and voltage/current in
corresponding format (Pr03-57 ~ Pr03-68), other analog input signals are calculated by using
bias and gain.
Set Pr03-50=7, all the analog input signals are calculated by using frequency and voltage/current
in corresponding format (Pr03-51 ~ Pr03-68)
AVI1 Low Point
Factory Setting: 0.00
Settings 03-28=0, 0.00~10.00V
03-28≠0, 0.00~20.00mA
AVI1 Proportional Low Point
Factory Setting: 0.00
Settings -100.00~100.00%
AVI1 Mid Point
Factory Setting: 5.00
Settings 03-28=0, 0.00~10.00V
03-28≠0, 0.00~20.00mA
AVI1 Proportional Mid Point
Factory Setting: 50.00
Settings 0.00~100.00%
AVI1 High Point
Factory Setting: 10.00
Settings 03-28=0, 0.00~10.00V
03-28≠0, 0.00~20.00mA
AVI1 Proportional High Point
Factory Setting: 100.00
Settings 0.00~100.00%
When Pr.03-28 = 0, AVI1 setting is 0-10V and the unit is in voltage (V).
When Pr.03-28 ≠ 0, AVI1 setting is 0-20mA or 4-20mA and the unit is in current (mA).
When setting analog input AVI1 to frequency command, it 100% corresponds to Fmax (Pr.01-00
Max. operation frequency).
