Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-09-17
Address of Communication Card (for DeviceNet and PROFIBUS)
Factory Setting: 1
Settings DeviceNet: 0-63
Profibus-DP: 1-125
Setting of DeviceNet Speed (according to Pr.09-72) (for DeviceNet and PROFIBUS)
Factory Setting: 2
Settings Standard DeviceNet:
0: 125Kbps
1: 250Kbps
2: 500Kbps
Non standard DeviceNet: (Delta only)
0: 10Kbps
1: 20Kbps
2: 50Kbps
3: 100Kbps
4: 125Kbps
5: 250Kbps
6: 500Kbps
7: 800Kbps
8: 1Mbps
Other Setting of DeviceNet Speed (for DeviceNet and PROFIBUS)
Factory Setting: 0
Settings 0: Standard DeviceNet
1: Nonstandard DeviceNet
It needs to use with Pr.09-71.
Setting 0: the baud rate can only be set to 0, 1, 2 or 3.
Setting 1: setting of DeviceNet communication rate can be the same as CANopen (setting 0-8).
Reserved
Reserved
IP Configuration of the Communication Card (for MODBUS TCP)
Factory Setting: 0
Settings 0: Static IP
1: DynamicIP (DHCP)
Setting 0: it needs to set IP address manually.
Setting 1: IP address will be auto set by host controller.
IP Address 1 of the Communication Card (for MODBUS TCP)
IP Address 2 of the Communication Card (for MODBUS TCP)
IP Address 3 of the Communication Card (for MODBUS TCP)
IP Address 4 of the Communication Card (for MODBUS TCP)
Factory Setting: 0
Settings 0~65535
Pr.09-76~09-79 needs to use with communication card.
Address Mask 1 of the Communication Card (for MODBUS TCP)
