Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-12-3
Number of Motors to be connected
Factory Setting: 1
Settings 1 to 8
Number of Motors: Maximum 8 motors. After setting number of motor to be connected at the
same time, multi-function output terminals will follow automatically the setting as shown in the
table below.
P12-01 01 02 03 04 05 06 07 08
P02-13 55 55 55 55 55 55 55 55
P02-14 56 56 56 56 56 56 56
P02-15 57 57 57 57 57 57
P02-36 58 58 58 58 58
P02-37 59 59 59 59
P02-38 60 60 60
P02-39 61 61
P02-40 62
Table 1: Setting of Multi-function Output Terminal on Circulating Motors
Operating time of each motor (minutes)
Factory Setting: 0
Settings
0 to 65500
minutes
Setting of Fixed Time Circulation by minute. If Pr12-02 = 0, that means stop timing, the current
running motors will keep on operating until a stop command is given.
Delay Time due to the Acceleration (or the Increment ) at Motor Switching (seconds)
Factory Setting: 10
Settings 0.0 to 3600.0 seconds
Delay time when switching motors in seconds. When the current running motors reach the
time setting of Pr12-02, CFP2000 will follow the delay time setting of Pr12-03 and then switch to
run the next motors.
Delay Time due to the Deceleration ( or the Decrement) at Motor Switching (seconds)
Factory Setting: 10
Settings 0.0 to 3600.0 seconds
Delay time while fixed quantity circulation at Motor Switching (seconds)
Factory Setting: 100
Settings 0.0 to 3600.0 seconds
Fixed quantity circulation with PID
Sequential Diagram
In this mode, CFP2000 can control up to 4 motors to increase controlling flow quantity and pressure
range. When controlling flow quantity, motors will be in parallel connection. When controlling
pressure range, motors will be in series connection.
If need to increase flow quantity or pressure range, CFP2000 will increase first motor’s pressure
from 0Hz to the largest operating frequency. If output frequency reaches the frequency setting of
