Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-12-6
 Parameter Setting
Parameter
setting
Description
P12-00=2
Choose Fixed quantity circulation with PID
P12-01=X
Number of Motors: Maximum 4 motors. After setting number of motor to be connected at
the same time, multi-function output terminals will follow automatically the setting as
shown in the table below.
P12-01 01 01 02 02 03 03 04 04
P02-13 55 55 55 55 55 55 55 55 Motor #1 by Drive
P02-14 56 56 56 56 56 56 56 Motor #1 by Mains
P02-15 57 57 57 57 57 57 Motor #2 by Drive
P02-36 58 58 58 58 58 Motor #2 by Mains
P02-37 59 59 59 59 Motor #3 by Drive
P02-38 60 60 60 Motor #3 by Mains
P02-39 61 61 Motor #4 by Drive
P02-40 62 Motor #4 by Mains
Table 2: Setting of Multi-function Output Terminal on Circulating Motors
P12-03=X Delay Time due to the Acceleration (or the Increment ) at Motor Switching ( unit: second)
P12-04=X Delay Time due to the Deceleration ( or the Decrement) at Motor Switching ( unit: sec)
P12-05=X Delay time while fixed quantity circulation at Motor Switching with PID (unit: seconds)
P12-06=X Frequency when switching motors at fixed quantity circulation (Hz)
 Disable Motor Output
Set the Multifunction Input Commands as Disable Motors’ Output can stop corresponding motors.
The settings are:
P02-01~P02-06= 60 61 62 63 64 65 66 67 68
Disable Motor Output ALL 1 2 3 4 5 6 7 8
When a motor’s output is disabled, this motor will park freely
