Delta VFD9A0MS43ANSHA User Manual

Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-09-15

Setting of DeviceNet Speed
Factory Setting: 2
Settings Standard DeviceNet:
0: 125 Kbps
1: 250 Kbps
2: 500 Kbps
3: 1 Mbps (Delta Only)
Non standard DeviceNet: (Delta only)
0: 10 Kbps
1: 20 Kbps
2: 50 Kbps
3: 100 Kbps
4: 125 Kbps
5: 250 Kbps
6: 500 Kbps
7: 800 Kbps
8: 1 Mbps

Other Setting of DeviceNet Speed
Factory Setting: 0
Settings 0: Disable
In this mode, baud rate can only be 125 Kbps, 250 Kbps, 500 Kbps,
1 Mbps in standard DeviceNet speed
1: Enable
In this mode, the baud rate of DeviceNet can be same as CANopen (0-8).
 It needs to use with Pr. 09-71.
 Setting 0: the baud rate can only be set to 0, 1, 2 or 3.
 Setting 1: setting of DeviceNet communication rate can be the same as CANopen (setting 0-8).

IP Configuration of the Communication Card
Factory Setting: 0
Settings 0: Static IP
1: Dynamic IP (DHCP)
 Setting 0: it needs to set IP address manually.
 Setting 1: IP address will be auto set by host controller.

IP Address 1 of the Communication Card

IP Address 2 of the Communication Card

IP Address 3 of the Communication Card

IP Address 4 of the Communication Card
Factory Setting: 0
Settings 0~255
 Pr. 09-76~09-79 should be used with communication card.
