Chapter 15 CANopen OverviewMS300 (High Speed Model)
15-24
Setting
*
Display
Fault
code
Description
CANopen
fault register
(bit 0~7)
CANopen
fault code
49
EoL2
Thermal relay 2
Fault
EF
External Fault
Fault
0031H
External Fault. When the multi-function
input terminal (EF) is active, the AC
motor drive will stop output.
5 9000H
50
EoL2
Thermal relay 2
Fault
EF1
Emergency stop
Fault
0032H
Emergency stop. When the
multi-function input terminal (EF1) is
active, the AC motor drive will stop
output.
5 9000H
51
EoL2
Thermal relay 2
Fault
bb
Base block
Fault
0033H
External Base Block. When the
multi-function input terminal (B.B) is
active, the AC motor drive will stop output.
5 9000H
52
EoL2
Thermal relay 2
Fault
Pcod
Password Error
Fault
0034H
Keypad is locked after enter wrong
password three times.
5 FF26H
54
EoL2
Thermal relay 2
Fault
cE1
Modbus CMD err
Fault
0036H
Modbus function code error (Illegal
function code)
4 7500H
55
Thermal relay 2
Fault
cE2
Modbus ADDR err
Fault
0037H
Modbus data address is error [ Illegal
data address (00 H to 254 H) ]
4 7500H
56
Thermal relay 2
Fault
cE3
Modbus DATA err
Fault
0038H Modbus data error (Illegal data value) 4 7500H
57
Thermal relay 2
Fault
cE4
Modbus slave FLT
Fault
0039H
Modbus communication error (Data is
written to read-only address)
4 7500H
58
Thermal relay 2
Fault
cE10
Modbus time out
Fault
003AH Modbus transmission time-out 4 7500H
61
Thermal relay 2
Fault
ydc
Y-delta connect
Fault
003DH Y-connection / ∆-connection switch error 2 3330H
62
Thermal relay 2
Fault
dEb
Dec. Energy back
Fault
003EH
Energy regeneration when decelerating
2 FF27H
