Speaker configuration and “Amp Assign” settings
This unit has a built-in 15-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by
changing the “Amp Assign” settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone
playback. (v p. 213)
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed. (v p. 213)
Playback speaker in each zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2 ZONE3
5.1-channel playback
2-channel (Pre-out) 2-channel (Pre-out)
Can be set in all “Amp
Assign” modes.
47
7.1-channel playback 48
9.1-channel playback 13.1ch + ZONE2 50
11.1-channel playback 13.1ch + ZONE2 53
13.1-channel playback (Dolby Atmos and Auro-3D) 15.1ch (Default) 59
15.1-channel playback for Dolby Atmos 15.1ch (Default) 59
15.1-channel for Dolby Atmos and 13.1ch for Auro-3D 15.1ch (Default) 60
13.1-channel playback (bi-amp connection of front
speakers)
13.1ch (Bi-Amp) 61
7.1-channel playback (bi-amp connection of all
channels)
7.1ch Full Bi-Amp 62
Second front speakers 13.1ch + Front B 64
13.1-channel playback
2-channel
(Speaker out)
2-channel (Pre-out) 13.1ch + ZONE2 65
13.1-channel playback 2-channel (Pre-out)
2-channel
(Speaker out)
13.1ch + ZONE3 65
