151

[3] ZONE4 playback

The AVC-A1XV is equipped with pre-out terminals for which the volume is adjustable as the ZONE4 output terminals.

2 ZONE4 STEREO/MONO system

• Stereo and monaural sound can be enjoyed in ZONE4. (By default, “STEREO” is selected.)

• When only one speaker is being used in ZONE4, select “MONO” for the ZONE4 channel setting at “7-1. Channel Setup” in the System

Setup Menu.

AVC-A1XVDVD player

Input

Monitor

MAIN ZONE 9.1-channel system

ZONE4 AUDIO OUT

(VARIABLE OUT)

Power amplifier

ZONE4 STEREO/MONO system

FL FR

Power amplifier

MULTI SOURCE AUDIO signal cable
