Denon AVR-1306 User Manual

ENGLISH
31
Advanced Operation
ENGLISH
Remote control unit
Operating DENON audio components
Advanced Operation
1
Set the MODE 1 switch to “AUDIO”.
2
Set the MODE 2 switch to the position for the
component to be operated (CD, CDR/MD or
TAPE).
3
Operate the audio component.
For details, refer to the component’s operating instructions.
While this remote control is compatible with a wide range of
infrared controlled components, it may be the case that some
component models cannot be operated with this remote
control.
MODE 2
ON/SOURCE
MODE 1
NUMBER
OFF
1. CD player (CD), CD recorder and MD recorder (CDR/MD)
system buttons
6, 7 : Manual search (forward and reverse)
2 : Stop
1 : Play
8, 9 : Auto search (cue)
3 : Pause
DISC SKIP + : Switch discs (for CD changers only)
2. Tape deck (TAPE) system buttons
6 : Rewind
7 : Fast-forward
2 : Stop
1 : Forward play
0 : Reverse play
A/B : Switch between decks A and B
3. Tuner system buttons
SHIFT : Switch preset channel range
CHANNEL +, – :Preset channel up/down
TUNING +, – :Frequency up/down
BAND : Switch between the AM and FM bands
MODE : Switch between auto and mono
MEMORY :Preset memory
• TUNER can be operated when the switch is at “AUDIO” position.

Denon AVR-1306 Specifications

General

Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Component Video Inputs	2
Digital Audio Inputs	2 Optical, 1 Coaxial
AM/FM Tuner	Yes
Dolby Digital	Yes
DTS	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Preset Station Qty	56
Frequency Response	10 Hz - 100 kHz
Amplifier Output Details	75.0 Watt - 8.0 Ohm - 20 - 20000 Hz - THD 0.08 %
Tuning Range	FM: 87.5 - 108.0 MHz, AM: 522 - 1611 kHz
Tuning Display	Fluorescent
Connector Type	RCA
Speaker Impedance	6 - 16 Ohm
Dimensions	434 x 151 x 363mm (W x H x D)
Channels	7.1
Weight	10.5 kg
