For optimum surround playback, adjustment of the distance of speakers and
sound level of each channel, using the test tone, are required, depending on the
environment for speakers to be used.
The settings for the following 5 items should be made:
Crossover Freq.
Channel Level
Distance
Bass Setting
Speaker Confi g.
Select speaker confi guration and size (bass
reproduction capability).
Set subwoofer and LFE signal range playback.
Set distance from listening position to speakers.
Measure beforehand the distance from the
listening position to each speaker.
Set the volume of the test tone to be the same
when it is output from each speaker.
Set the maximum frequency of the bass signal
output from each channel to the subwoofer.
Set the Crossover Frequency to suit the bass
reproduction capability of the speaker being used.
Menu operation
1
Press MENU.
The menu is displayed on the TV screen of
this unit.
Speaker Setup
Input Setup
Option Setup
Speaker Config.
Bass Setting
Distance
Channel Level
Crossover Freq.
[ ][ENTER] Enter Return
MENU
2
Press ENTER.
3
Use ui to select the menu to be set
or operated, and then press
ENTER.
4
Use o p to select a detailed setting,
and then press
ENTER.
• To return to the previous item, press RETURN
B
.
• Exiting the Menu, press
MENU while the menu
is displayed.
The menu display disappears.
Set up speakers
Speaker Confi g.
Default settings are underlined.
1
Press MENU.
The menu is displayed on the TV screen of
this unit.
Speaker Setup
Input Setup
Option Setup
Speaker Config.
Bass Setting
Distance
Channel Level
Crossover Freq.
MENU
2
Use ui to select “Speaker Setup”,
and then press
ENTER.
Speaker Config.
Bass Setting
Distance
Channel Level
Crossover Freq.
Front
Center
Surround
Surround Back
Subwoofer
Speaker Setup
3
Use ui to select “Speaker Con g.”,
and then press
ENTER.
Front
Center
Surround
Surround Back
Subwoofer
Large
Small
Small
None
Yes
1
Speaker Config.
NOTE
Do not use the outward shape of the speaker
to determine selection of a “Large” or “Small”
speaker. Instead, use the frequencies set in
“Crossover Freq.” (vpage 8) as the standard
for determining bass reproduction capability.
4
Use ui to select a speaker, and use
o p to select a detailed setting.
Items to be set are shown below.
Front
Set the front speaker size.
• Large : Use a large speaker that can adequately
play back low frequencies.
• Small : Use a small speaker that has inadequate
playback capacity for low frequencies.
• When “Subwoofer” is set to “No”, “Front” is
automatically set to “Large”.
• When “Front” is set to “Small”, “Center”,
“Surround“ and “Surround Back” can not be
set to “Large”.
Center
Set the presence and size of the
center speaker.
• Large : Use a large speaker that can adequately
play back low frequencies.
• Small : Use a small speaker that has inadequate
playback capacity for low frequencies.
• None : Select when a center speaker is not
connected.
“Large” is not displayed when “Front” is set
to “Small”.
Surround
Set the presence and size of the
surround speakers.
• Large : Use a large speaker that can adequately
play back low frequencies.
• Small : Use a small speaker that has inadequate
playback capacity for low frequencies.
• None : Select when the surround speakers are
not connected.
• When “Surround” is set to “Large”, “Surround
Back” can be set to “Large”.
• When “Surround” is set to “None”, “Surround
Back” can automatically set to “None”.
vSee overleaf
