59
Speaker Setup
Default settings are underlined.
Perform when setting the speakers manually or when changing settings made in Audyssey
®
Auto Setup.
•If you change the speaker settings after performing Audyssey
®
Auto Setup, it will not be possible to
select Audyssey MultEQ
®
, Audyssey Dynamic EQ
®
and Audyssey Dynamic Volume
®
(vpage 54,
55).
•“System Setup” can be used without changing the settings. Please set if necessary.
Setting items Setting details
Pre Assign
The signal output from
the SURR.BACK/FRONT
HEIGHT terminals on PRE
OUT of the amplifier can be
switched in accordance with
the speaker environment.
NORMAL : Set for connecting the surround back speakers to the SURR.
BACK/FRONT HEIGHT connector in PRE OUT.
F.HEIGHT : Set for connecting the front height speakers to the SURR.
BACK/FRONT HEIGHT connector in PRE OUT.
A power amplifier (sold separately) is required for this connection.
Speaker Config.
Select speaker configuration
and size (bass reproduction
capability).
NOTE
Do not use the outward
shape of the speaker to
determine selection of a
“Large” or “Small” speaker.
Instead, use the frequencies
set in “Crossover Freq.”
(vpage61) as the
standard for determining
bass reproduction capability.
Front : Set the front speaker size.
•Large : Use a large speaker that can adequately play back low
frequencies.
•Small : Use a small speaker that has inadequate playback capacity for
low frequencies.
•When “Subwoofer” is set to “No”, “Front” is automatically set to
“Large”.
•When “Front” is set to “Small”, “Center”, “Surround“, “S.Back” and
“F.Height” can not be set to “Large”.
Center : Set the presence and size of the center speaker.
•Large : Use a large speaker that can adequately play back low
frequencies.
•Small : Use a small speaker that has inadequate playback capacity for
low frequencies.
•None : Select when a center speaker is not connected.
“Large” is not displayed when “Front” is set to “Small”.
System Setup
Setting items Setting details
Speaker Config.
(Continued)
Subwoofer : Set the presence of a subwoofer.
•Yes : Use a subwoofer.
•No : Select when a subwoofer is not connected.
When “Front” is set to “Small”, “Subwoofer” is automatically set to
“Yes”.
Surround : Set the presence and size of the surround speakers.
•Large : Use a large speaker that can adequately play back low
frequencies.
•Small : Use a small speaker that has inadequate playback capacity for
low frequencies.
•None : Select when the surround speakers are not connected.
•When “Surround” is set to “Large”, “S.Back” and “F.Height” can be
set to “Large”.
•When “Surround” is set to “None”, “S.Back” and “F.Height” are
automatically set to “None”.
S.Back : Set the presence, size and number of surround back speakers.
•Large : Use a large speaker that can adequately play back low
frequencies.
•Small : Use a small speaker that has inadequate playback capacity for
low frequencies.
•None : Select when the surround back speakers are not connected.
•2spkrs : Use two surround back speakers.
•1spkr : Use only one surround back speaker. When you select this
setting, connect the surround back speaker to the left (L) channel.
Even when the “S.Back“ setting is other than “None”, sound may
not be emitted from the surround back speaker, depending on the
playback source. In this case, make “Surr.Parameter” – “S.Back”
setting other than “OFF” (vpage53).
NOTE
When “Pre Assign” setting (vpage59) is “NORMAL”, you can make
the “S.Back” setting.
To Next Page
