This unit is equipped with a digital signal processing circuit that lets you play program sources in the surround mode to achieve the same sense of presence as in a movie theater.
Surround modes and surround parameters
This table shows the speakers that can be used in each surround mode and the surround parameters adjustable in each surround mode.
Symbols in the table
S This indicates the audio output channels or surround parameters that can be set.
D This indicates the audio output channels. The output channels depend on the settings of “Speaker Config.” (vpage59).
Surround mode (vpage29)
Channel output
Surr.Parameter (vpage52)
Front
L/R
Center
Surround
L/R
Surround Back
L/R
Front Height L/R Subwoofer
Mode
(vpage52)
Cinema EQ.
(vpage52)
DRC
z8
(vpage52)
D. Comp
z9
(vpage52)
LFE
z10
(vpage52)
Delay Time
(vpage52)
Effect Level
(vpage52)
Room Size
(vpage52)
DIRECT (2channel)
S D
z3
S S
DIRECT (Multi-channel)
S D D D
z1
D
z1
D S S S
STEREO
S D S S S
MULTI CH IN
S D D D D
z2
D S S
DOLBY PRO LOGIC gz S D D D D S
z4
S S S
DOLBY PRO LOGIC gx S D D D D S S
z5
S S
DOLBY PRO LOGIC g S D D D S S
z6
S S
DTS NEO:6
S D D D D S S
z5
S S
DOLBY DIGITAL
S D D D D
z2
D S
z7
S S
DOLBY DIGITAL Plus
S D D D D
z2
D S
z7
S S
DOLBY TrueHD
S D D D D
z2
D S
z7
S S
DTS SURROUND
S D D D D
z2
D S
z7
S S
DTS 96/24
S D D D D
z2
D S
z7
S S
DTS-HD
S D D D D
z2
D S
z7
S S
DTS Express
S D D D D
z2
D S
z7
S S
MULTI CH STEREO
S D D D D D S S S
ROCK ARENA
S D D D D D S S S S S
JAZZ CLUB
S D D D D D S S S S S
MONO MOVIE
S D D D D D S S S S S
VIDEO GAME
S D D D D D S S S S S
MATRIX
S D D D D D S S S S
VIRTUAL
S D S S S
z1 A signal for each channel contained in an input signal is output as audio.
z2 If “Surr.Parameter” – “PLgz Height” (vpage53) is set to “ON”, sound is output from the front height speakers.
z3 Only when “Subwoofer Mode” is set to “LFE+Main” (vpage60), sound is output from the subwoofer.
z4 If this surround mode is selected, only the “Height” mode setting is available for “Surr.Parameter” – “Mode” (vpage52).
z5 This item can be selected when “Surr.Parameter” – “Mode” (vpage52) is set to “Cinema”.
z6 This item can be selected when “Surr.Parameter” – “Mode” (vpage52) is set to “Cinema” or “Pro Logic”.
z7 This item cannot be set when “Surr.Parameter” – “S.Back” (vpage53) is set to “PLgx Music”.
z8 This item can be selected when a Dolby TrueHD signal is played.
z9 This item can be selected when a Dolby Digital or DTS signal is played.
z10 This item can be selected when a Dolby Digital or DTS signal or DVD-Audio is played.
