Denon AVR-1909 Service Manual

112
AVR-1909/789, AVC-1909
Q1033 00D9630120801 TR KRC102S J522010200210S
Q1034 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q1035 00D9630120801 TR KRC102S E3 J522010200210S
Q1036 00D9630120704 TR KRA102S E3 J520010200210S
Q1037 00D9630120801 TR KRC102S E3 J522010200210S
Q1038 00D9630120704 TR KRA102S E3 J520010200210S
Q1039 963219002180S TR 2SD2114KT146W J5232114K0010S
Q1040,1041 00D9630121509 TR KTC3875S J522038750210S
Q1042 00D2750110905 FET HN1K02FU J543102000010S
Q1043 00D9630121509 TR KTC3875S J522038750210S
Q1044 00D9600285006 TR KRC104S J522104S00210S
Q1045 00D9630120801 TR KRC102S J522010200210S
Q1046 00D9600285006 TR KRC104S J522104S00210S
Q1047 00D9630121402 TR 2SA KRA104S R1 J520010400210S
Q1049 963219002190S TR 2SA KTA1242D-Y J500124200010S
Q1050 00D9630120801 TR KRC102S J522010200210S
Q1051 00D9630120801 TR KRC102S E3 J522010200210S
Q1052 963219002190S TR 2SA KTA1242D-Y E3 J500124200010S
D1041 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D1042,1043 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D1046-1054 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D1057,1058 00D9630341305 D,ESD IMSA-6802-01A E3 K067680200010S
D1059 00D9630245100 D,SWITCHING KDS226ST1(C3) E3 K005022600020S
D1060 00D9630355401 D,SWITCHING KDS4148U K005041480030S
ZD1002 00D9630382500 D,ZENER 0.2W 5.1V UDZ K06605R14P400S
CAPACITORS GROUP
C1001-1003 nsp C,CERAMIC 0.1UF-K/50V
D011104177101S
C1004-1006 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1007 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1008 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1009,1010 nsp C,CERAMIC 4.7UF-Z/6.3V D011475591160S
C1011,1012 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1018 nsp C,CERAMIC 4.7UF-Z/6.3V D011475591160S
C1019 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1020 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1021,1022 nsp C,CERAMIC 100PF-J/50V D011101167101S
C1023 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1024-1027 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1028,1029 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1030-1032 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1039 nsp C,CERAMIC 4.7UF-Z/6.3V D011475591160S
C1046-1053 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1054-1057 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1058-1067 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1068-1071 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1072 963134002270S C,ELECT 100UF-MVK/6.3V D050101181200S
C1073-1075 nsp C,CERAMIC 4.7UF-Z/6.3V D011475591160S
C1076-1078 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1079 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1080 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1081 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1082 nsp C,CERAMIC 0.1UF-K/50V D011102177101S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1909 Specifications

General

Speakers connectivity type	-
HDMI version	1.3a
Product color	Black
x.v.Color support	Yes
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	3
Number of HDMI outputs	1
Ethernet LAN	No
