Denon AVR-1909 - FLI2310 Terminal Function

46
AVR-1909/789, AVC-1909
FLI2310 Terminal Function
ab e 3 3 0 p de a s
Pin
No Pin Name I/O Type
Voltage
Tolerance Drive
Pull up/
Pulldown Description
1
HSYNC1_PORT1 Input 5v
Horizontal sync or reference -CTL1 of Port 1
2
VSYNC1_PORT1 Input 5v
Vertical sync or reference -CTL1 of Port 1
3
FIELD ID1_PORT1
Input 5v
Odd/Even Field identification -CTL1 of Port 1
4
IN_CLK1_PORT1
Input 5v
Data Clock input -CTL1 of Port 1
5
HSYNC2_PORT1 Input 5v
Horizontal sync or reference –CTL2 of Port 1
6
VSYNC2_PORT1 Input 5v
Vertical sync or reference –CTL2 of Port 1
7
FIELD ID2_PORT1
Input 5v
Odd/Even Field identification –CTL2 of Port 1
8
VDD1
Power 3.3 V - Power pin for IO
9
VSS
Ground Ground
10
IN_CLK2_PORT1
Input 5v
Data Clock input –CTL2 of Port 1
11
B/Cb/D1_0
Input 5v
Port 1 – Digital video input (Blue/Cb/D1)
12
B/Cb/D1_1
Input 5v
Port 1 – Digital video input (Blue/Cb/D1)
13
B/Cb/D1_2
Input 5v
Port 1 – Digital video input (Blue/Cb/D1)
14
B/Cb/D1_3
Input 5v
Port 1 – Digital video input (Blue/Cb/D1)
15
B/Cb/D1_4
Input 5v
Port 1 – Digital video input (Blue/Cb/D1)
16
VDDcore1
Power 1.8 V - Power pin for core
17
VSScore
Ground Ground
18
B/Cb/D1_5
Input 5v
Port 1 – Digital video input (Blue/Cb/D1)
19
B/Cb/D1_6
Input 5v
Port 1 – Digital video input (Blue/Cb/D1)
20
B/Cb/D1_7
Input 5v
Port 1 – Digital video input (Blue/Cb/D1)
21
R/Cr/Cb Cr_0
Input 5v
Port 1 – Digital video input (Red/Cr/CrCb)
22
R/Cr/Cb Cr_1
Input 5v
Port 1 – Digital video input (Red/Cr/CrCb)
23
R/Cr/Cb Cr_2
Input 5v
Port 1 – Digital video input (Red/Cr/CrCb)
24
R/Cr/Cb Cr_3
Input 5v
Port 1 – Digital video input (Red/Cr/CrCb)
25
R/Cr/Cb Cr_4
Input 5v
Port 1 – Digital video input (Red/Cr/CrCb)
26
R/Cr/Cb Cr_5
Input 5v
Port 1 – Digital video input (Red/Cr/CrCb)
27
R/Cr/Cb Cr_6
Input 5v
Port 1 – Digital video input (Red/Cr/CrCb)
28
R/Cr/Cb Cr_7
Input 5v
Port 1 – Digital video input (Red/Cr/CrCb)
29
G/Y/Y_0
Input 5v
Port 1 – Digital video input (Green/Y)
30
VDD2
Power 3.3 V - Power pin for IO
31
VSS
Ground Ground
32
G/Y/Y_1
Input 5v
Port 1 – Digital video input (Green/Y)
33
G/Y/Y_2
Input 5v
Port 1 – Digital video input (Green/Y)
34
G/Y/Y_3
Input 5v
Port 1 – Digital video input (Green/Y)
35
G/Y/Y_4
Input 5v
Port 1 – Digital video input (Green/Y)
36
VDDcore2
Power 1.8 V - Power pin for core
37
VSScore
Ground Ground
38
G/Y/Y_5
Input 5v
Port 1 – Digital video input (Green/Y)
39
G/Y/Y_6
Input 5v
Port 1 – Digital video input (Green/Y)
40
G/Y/Y_7
Input 5v
Port 1 – Digital video input (Green/Y)
41
IN_SEL Output 5v 8 mA
Output to select external video mux
42 TEST Input 5v
Connect to Ground
43
DEV_ADDR1 Input 5v
Device address setting 1
44
DEV_ADDR0 Input 5v
Device address setting 0
