AVR-1909/789, AVC-1909
DISASSEMBLY
• Disassemble in order of the arrow of the figure of following flow.
下記フロー図の矢印の順番にはずしてください。
• In the case of the re-assembling, assemble it in order of the reverse of the following flow.
再組み立ての場合は、下記のフローの逆の順番に組立ててください
• In the case of the re-assembling, observe "attention of assembling" it.
再組み立ての場合は、「組立のご注意」を遵守してください。
㩷
FRONT P.W.B ASSY HDMI P.W.B ASSY VIDEO P.W.B ASSY
(Ref. No. of EXPLODED VIEW : BF1) (Ref. No. of EXPLODED VIEW : BH1) (Ref. No. of EXPLODED VIEW : BV1)
V- AUX P.W.B ASSY
(Ref. No. of EXPLODED VIEW : BF2)
MIC P.W.B ASSY
(Ref. No. of EXPLODED VIEW : BF3)
FUNC P.W.B ASSY
(Ref. No. of EXPLODED VIEW : BF4) SIRIUS P.W.B ASSY CPU P.W.B ASSY
HEAD PHONE P.W.B ASSY (Ref. No. of EXPLODED VIEW : BS1) (Ref. No. of EXPLODED VIEW : BC1)
(Ref. No. of EXPLODED VIEW : BF6) INPUT P.W.B ASSY
POWER SW P.W.B ASSY (Ref. No. of EXPLODED VIEW : BI1)
(Ref. No. of EXPLODED VIEW : BF7)
ENCORDER P.W.B ASSY
(Ref. No. of EXPLODED VIEW : BF8)
TUNER PACK
(Ref. No. of EXPLODED VIEW : PR1)
MAIN P.W.B ASSY
TRANS CHASSIS BACK SUB ASSY
(Ref. No. of EXPLODED VIEW : BM1)
Refer to "DISASSEMBLY
2CH P.W.B ASSY
5.CHASSIS BACK SUBASSY"
(Ref. No. of EXPLODED VIEW : B21)
and "EXPLODED VIEW"
TRANS CHASSIS BACK SUB ASSY
(Ref. No. of EXPLODED VIEW : W8) (Ref. No. of EXPLODED VIEW : C2)
SPEAKER P.W.B ASSY
(Ref. No. of EXPLODED VIEW : BF5)
POWER P.W.B ASSY
(Ref. No. of EXPLODED VIEW : BP1)
POWER SUPPLY P.W.B ASSY
(Ref. No. of EXPLODED VIEW : BP2)
and "EXPLODED VIEW"
VIDEO P.W.B ASSY
Refer to "DISASSEMBLY
6.VIDEO P.W.B ASSY"
and "EXPLODED VIEW"
INPUT / CPU P.W.B ASSY
Refer to "DISASSEMBLY
7.INPUT / CPU P.W.B ASSY"
and "EXPLODED VIEW"
MAIN P.W.B SUB ASSY
POWER P.W.B SUB ASSY
Refer to "DISASSEMBLY
9.POWER P.W.B SUB ASSY"
Refer to "DISASSEMBLY
8.MAIN P.W.B SUB ASSY"
and "EXPLODED VIEW"
TUNER PAC
Refer to "DISASSEMBLY
4.TUNER PACK"
and "EXPLODED VIEW"
and "EXPLODED VIEW"
3.SIRIUS P.W.B ASSY"
Refer to "DISASSEMBLY
SIRIUS P.W.B ASSY
and "EXPLODED VIEW"
2.HDMI P.W.B ASSY"
Refer to "DISASSEMBLY
HDMI P.W.B ASSY
and "EXPLODED VIEW"
Refer to "DISASSEMBLY
10.TRANS"
and "EXPLODED VIEW"
CABINET TOP
PANEL FRONT SUB ASSY
Refer to "DISASSEMBLY
1.PANEL FRONT SUB ASSY"
