Denon AVR-1909 Service Manual

121
AVR-1909/789, AVC-1909
C2112,2113 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C2114 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C2115 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C2116 00D9630234205 C,ELECT 10UF-M/50V E3, E2, EA D040100087070S
C2117 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C2118,2119 00D9630294203 C,ELECT 33UF-M/16V D040330083050S
C2120 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C2121,2122 00D9630234205 C,ELECT 10UF-M/50V E3, E2, EA D040100087070S
C2123 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C2124,2125 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C2126 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2127 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C2128 00D9630234205 C,ELECT 10UF-M/50V E3, E2, EA D040100087070S
C2129 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C2130 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C2131 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C2132,2133 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C2134,2135 00D9630294203 C,ELECT 33UF-M/16V D040330083050S
C2136 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C2137,2138 00D9630234205 C,ELECT 10UF-M/50V E3, E2, EA D040100087070S
C2139 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C2140-2142 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2143 00D9630234205 C,ELECT 10UF-M/50V E3, E2, EA D040100087070S
C2144,2145 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C2146 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C2147 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C2148 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C2149 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C2150 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C2151 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C2152 nsp C,CERAMIC 220PF-J/50V D010221167160S
C2153 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C2155 00D2544651900 C,ELECT 330UF-M/6.3V D041331081020S
C2157 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2161 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2162 00D9639003097 C,FILM 0.1UF-K/250V D02010407H080S
C2164,2165 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2167,2168 nsp C,CERAMIC 0.01UF-K/50V JP D011103777160S
C2169 00D9639006214 C,ELECT 3.3UF-M/50V D0403R3087050S
C2170 00D9639006214 C,ELECT 3.3UF-M/50V E3, E2, EA D0403R3087050S
C2170 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) JP D040010087150S
C2301-2303 00D9630234205 C,ELECT 10UF-M/50V JP D040100087070S
C2304-2306 nsp C,CERAMIC 100PF-J/50V JP D010101167160S
C2307-2309 00D9630234205 C,ELECT 10UF-M/50V JP D040100087070S
C2310-2312 nsp C,CERAMIC 100PF-J/50V JP D010101167160S
C2313-2315 00D9630234205 C,ELECT 10UF-M/50V JP D040100087070S
C2316-2321 nsp C,CERAMIC 100PF-J/50V JP D010101167160S
OTHERS PARTS GROUP
BD2001,2002 00D9630223009 R,THICK 0-J,1/16W
C20000006M160S
BD2003 nsp COIL,BEAD MB-160808 D340160800060S
CN1005 nsp CN,WIRE 7P L002201070060S
CN2001 nsp CN.WAFER 12P L101100031210S
CN2002 nsp CN.WAFER 5P L101100030510S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1909 Specifications

General

Speakers connectivity type	-
HDMI version	1.3a
Product color	Black
x.v.Color support	Yes
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	3
Number of HDMI outputs	1
Ethernet LAN	No
