Denon AVR-1909 Service Manual

124
AVR-1909/789, AVC-1909
R421SBR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R422SBL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R422SBR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R423SBL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R423SBR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R424SBL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R424SBR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R429SBL 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R429SBR 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R430SBL 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R430SBR 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R437 00D9630337908 R,METAL FILM 33-J,1W C060033065050S
VR401,402 00D9630366407 VR,SEMI CARBON
EVN-DCAA03B 1KB
C541102315000S
CAPACITORS GROUP
C402SBL 00D9630234205 C,ELECT 10UF-M/50V
D040100087070S
C402SBR 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C403SBL 00D9630367101 C,CERAMIC 220PF-J/500V D00422106D05CS
C403SBR 00D9630367101 C,CERAMIC 220PF-J/500V D00422106D05CS
C404SBL 00D9630338208 C,CERAMIC 470PF-K/500V D00447127D050S
C404SBR 00D9630338208 C,CERAMIC 470PF-K/500V D00447127D050S
C405SBL 00D9630216100 C,CERAMIC 33PF-J/500V D00033006D050S
C405SBR 00D9630216100 C,CERAMIC 33PF-J/500V D00033006D050S
C406SBL 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C406SBR 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C407SBL 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C407SBR 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C408SBL 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C408SBR 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C410SBL 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C410SBR 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C413SBL nsp C,FILM 0.1UF-J/50V D020104167050S
C413SBR nsp C,FILM 0.1UF-J/50V D020104167050S
C427 00D9630382403 C,ELECT 15000UF-M/16V D040153083000S
C428 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C429 00D9639005875 C,ELECT 47UF-M/25V E3 D040470084070S
C429 00D9600298802 C,ELECT 470UF-M/6.3V E2, EA, JP D040471081070S
C430 00D9630234205 C,ELECT 10UF-M/50V E3 D040100087070S
C430 00D9600298802 C,ELECT 470UF-M/6.3V E2, EA, JP D040471081070S
C431,432 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C433 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C434 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C435 00D9630276409 C,ELECT 100UF-M/16V E3 D040101083090S
C435 00D9600298802 C,ELECT 470UF-M/6.3V E2, EA, JP D040471081070S
C436,437 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C438 00D9630276409 C,ELECT 100UF-M/16V E3 D040101083090S
C439 00D9609009940 C,ELECT 1000UF-M/16V E2, EA, JP D040102083030S
C440 00D9600133404 C,ELECT 10000UF 16V E3 D040103083020S
C441 00D9630255608 C,ELECT 33UF-M/25V D040330084050S
C442 00D9630024703 C,FILM 0.01UF-J/100V D02010306C060S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1909 Specifications

General

Speakers connectivity type	-
HDMI version	1.3a
Product color	Black
x.v.Color support	Yes
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	3
Number of HDMI outputs	1
Ethernet LAN	No
