Denon AVR-1909 Service Manual

130
AVR-1909/789, AVC-1909
B21 nsp 2CH P.W.B. UNIT ASSY AVR1909BKE3 7025HK0804014 1
B21 nsp 2CH P.W.B. UNIT ASSY
AVR1909BKE2 7025HK0804064 1
B21 nsp 2CH P.W.B. UNIT ASSY
AVR1909SPE2 7025HK0804054 1
B21 nsp 2CH P.W.B. UNIT ASSY
AVR789BKE3 7025HK0804024 1
B21 nsp 2CH P.W.B. UNIT ASSY
AVR789BKEA 7025HK0804044 1
B21 nsp 2CH P.W.B. UNIT ASSY
AVC1909JP 7025HK0804034 1
BC1 nsp CPU P.W.B. UNIT ASSY
AVR1909BKE3 7025HK0804015 1
BC1 nsp CPU P.W.B. UNIT ASSY
AVR1909BKE2 7025HK0804065 1
BC1 nsp CPU P.W.B. UNIT ASSY
AVR1909SPE2 7025HK0804055 1
BC1 nsp CPU P.W.B. UNIT ASSY
AVR789BKE3 7025HK0804025 1
BC1 nsp CPU P.W.B. UNIT ASSY
AVR789BKEA 7025HK0804045 1
BC1 nsp CPU P.W.B. UNIT ASSY
AVC1909JP 7025HK0804035 1
BV nsp VIDEO P.W.B. UNIT ASSY
AVR1909BKE3 7025HK0804016 1
BV nsp VIDEO P.W.B. UNIT ASSY
AVR1909BKE2 7025HK0804066 1
BV nsp VIDEO P.W.B. UNIT ASSY
AVR1909SPE2 7025HK0804056 1
BV nsp VIDEO P.W.B. UNIT ASSY
AVR789BKE3 7025HK0804026 1
BV nsp VIDEO P.W.B. UNIT ASSY
AVR789BKEA 7025HK0804046 1
BV nsp VIDEO P.W.B. UNIT ASSY
AVC1909JP 7025HK0804036 1
BV1 nsp VIDEO UNIT
AVC1909JP only 7028066811010
BV2 nsp DIN1 UNIT AVC1909JP only 7028066812010
BV3 nsp DIN2 UNIT AVC1909JP only 7028066813010
BV4 nsp CNT UNIT AVC1909JP only 7028066814010
BH 963189000860D HDMI P.W.B. UNIT ASSY AVR1909BKE3/AVR789BKE3 7025HK0804017 1
BH 963189001430D HDMI P.W.B. UNIT ASSY
AVR1909BKE2/SPE2/BKEA/JP 7025HK0804067 1
BS nsp SIRIUS P.W.B. UNIT ASSY
AVR1909BKE3 7025HK0804018 1
BS nsp SIRIUS P.W.B. UNIT ASSY
AVR1909BKE2 7025HK0804068 1
BS nsp SIRIUS P.W.B. UNIT ASSY
AVR1909SPE2 7025HK0804058 1
BS nsp SIRIUS P.W.B. UNIT ASSY
AVR789BKE3 7025HK0804028 1
BS nsp SIRIUS P.W.B. UNIT ASSY
AVR789BKEA 7025HK0804048 1
BS nsp SIRIUS P.W.B. UNIT ASSY
AVC1909JP 7025HK0804038 1
BS1 - SIRIUS UNIT
BS2 - VIDEO CNT UNIT
BS3 - VIDEO CNT2 UNIT
BR nsp REG P.W.B. UNIT ASSY
AVR1909BKE3 7025HK0804019 1
BR nsp REG P.W.B. UNIT ASSY
AVR1909BKE2 7025HK0804069 1
BR nsp REG P.W.B. UNIT ASSY
AVR1909SPE2 7025HK0804069 1
BR nsp REG P.W.B. UNIT ASSY
AVR789BKE3 7025HK0804019 1
BR nsp REG P.W.B. UNIT ASSY
AVR789BKEA 7025HK0804069 1
BR nsp REG P.W.B. UNIT ASSY
AVC1909JP 7025HK0804069 1
BR1 - REG1 UNIT
BR2 - REG2 UNIT
BR3 - REG3 UNIT
BR4 - REG4 UNIT
BR5 - REG5 UNIT
BR6 - REG6 UNIT
P1 963409002050D SHEET WINDOW
1210210682000S 1
P2 963402000880D PANEL FRONT
AVR1909BKE3 3067213911000S 1
P2 963402000950D PANEL FRONT
AVR1909BKE2 3067213911100S 1
P2 963402000960D PANEL FRONT
AVR1909SPE2 3067213911200S 1
P2 963402000920D PANEL FRONT
AVR789BKE3 3067213901000S 1
Ref. No. Part Name Remarks Q'ty New

Denon AVR-1909 Specifications

General

Speakers connectivity type	-
HDMI version	1.3a
Product color	Black
x.v.Color support	Yes
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	3
Number of HDMI outputs	1
Ethernet LAN	No
